Strenx® Section 700MC
A wide range of high-strength structural steel
Strenx® Section 700MC is a cold-formed steel section made of hot-rolled, high-strength steel with a minimum yield strength of 700 MPa.
Its high-strength combined with naturally stiff form enables construction of stronger and lighter structures. Typical applications include demanding load-bearing structures in the lifting, handling and transportation segments.
The steel in Strenx® Section 700MC meets or exceeds the requirements of EN 10149-2. Its tolerances meet or exceed, when applicable, the requirements of EN 10162.
Strenx® Section 700MC is available as U-section. Other shapes and variations are available upon request. The maximum length of the sections is 21 meters, cut-to-length sections are available upon request.
Dimension Range
Strenx® Section 700MC is available as U-section. Other shapes and variations are available upon request.
|
Product type |
U-Section |
|---|---|
|
Bottom length (mm) |
50 – 400 |
|
Side length (mm) |
30 – 200 |
|
Wall thickness (mm) |
2.5 – 8.0 |
|
Max. length (mm) |
12000 |
Mechanical Properties
|
Thickness
(mm) |
Yield strength ReH 1)
(min MPa) |
Tensile strength Rm
(MPa) |
Elongation A80
(min %) |
Elongation A5
(%) |
Min. inner bending radius for a 90° bend
(x t) |
|---|---|---|---|---|---|
|
2.50 – 3.00 |
700 |
750 – 950 |
10 |
— |
0.8 |
|
3.01 – 6.00 |
700 |
750 – 950 |
— |
12 |
1.2 |
|
6.01 – 8.0 |
700 |
750 – 950 |
— |
12 |
1.5 |
The mechanical properties are tested in the longitudinal direction.
1) If ReH is not applicable then Rp0.2 is used. On thicknesses >8 mm the minimum yield strength may be 20 MPa lower.
Impact Properties
|
Product |
Min. impact energy for longitudinal testing,
Charpy V 10×10 mm test specimen 1) |
|---|---|
|
Strenx® Section 700MC |
27 J / -40 °C |
1) Impact testing according to EN ISO 148-1 is performed on thicknesses ≥ 6 mm. The specified minimum value corresponds to a full-size specimen.
Chemical Composition (ladle analysis)
|
C
(max %) |
Si
(max %) |
Mn
(max %) |
P
(max %) |
S
(max %) |
Nb
(max %) |
V
(max %) |
Ti
(max %) |
|---|---|---|---|---|---|---|---|
|
0.12 |
0.21 |
2.10 |
0.020 |
0.010 |
0.090 |
0.20 |
0.15 |
If the material is to be hot-dip galvanized according to category A or category B in EN 10149-2 this must be specified at the time of order.
Sum of Nb, V and Ti = max 0.22%
The steel is grain refined.
Carbon Equivalent CET(CEV)
|
Thickness (mm) |
2.5 – 8.00 |
|---|---|
|
Typ CET(CEV) |
0.24 (0.38) |
